Partnering with Fuji Electric and Soeho Electric, CSE Uniserve delivers, leading, reliable motor control and protection solutions to optimise operations across a range of applications.

  • The Fuji FRENIC Mini VSD is a compact, high-performance, multipurpose inverter with dynamic torque vector control for stable torque output even at low speeds. stable creep speed for more accurate stopping, and temperature, pressure, and flow rate control without an external device.

    Features

    • Dynamic Torque Vector Control System.
    • Slip Compensation shortens setting time.
    • Fastest CPU Processor in its Class.
    • Fully compatible and user-friendly.
    • Easy operation and maintenance.
    • Optional USB keypad is available.
    • Enhanced PC loader software (FRENIC Loader) connectivity.
    • Trip history saves and displays information on up to four past trips.
    • PID Control Function.
    • Cooling Fan ON/OFF Control Function.
    • Sensorless synchronous motor control to reduce energy consumption.
    • RS-485 Communications Port as standard.
  • The Fuji FRENIC HVAC VSD has been specifically designed to meet the requirements of HVAC customers, the Fuji Frenic HVAC provides energy savings by controlling water and air flow rates, pressure and temperatures within air conditioning systems.

    Features

    • Wide capacity range from 0.75 kW to 710 kW.
    • IP55 up to 90kW.
    • DCR Reactor and EMC filter built-in up to 90 kW / Built-in EMC filter for all capacities.
    • Modbus RTU, BACnet MS/TP, Metasys N2; integrated as standard.
    • A dedicated pump control function is provided as standard.
    • The first slim body design among the Fuji Electric inverters.
    • Temperature difference constant control and pressure difference constant control.
    • Energy saving functions, including wet-bulb temperature presumption control.
    • Automatic energy-saving operation.
  • The Fuji FRENIC Mega G2 Variable Speed Drive (VSD) delivers flexibility and functionality to support a wide range of applications on all types of mechanical equipment. The Fuji FRENIC Mega G2 VSD takes core capabilities, responsiveness, environmental awareness and easy maintenance to the next level.

    Features

    • Supports vector control, sensorless vector control, dynamic torque vector control, and V/f control.
    • Increases the maximum output frequency of all control systems to 599 Hz.
    • Improves speed and current responsiveness and stabilises quality.
    • Improved speed control range stabilises torque at low speeds.
    • Magnetic flux control minimises fluctuations and suppresses vibration.
    • Expansion of standard applied motor capacity for the HND specification
    • Expands the capacity of the built-in braking Expansion transistor type.
